Product Images	Model Name	Description	Channel	Input Type	Sampling rate	Datasheet
	APAX-5017H	12-ch High Speed Analog Input Module	12	V, mV, mA	1,000 sample/second (per channel)
	APAX-5017	12-ch Analog Input Module	12	V, mV, mA	12 (Total)
	APAX-5018	12-ch Thermocouple Input Module	12	V, mV, mA, Thermocouple	12 (Total**)
	APAX-5017PE	IEC 61850-3 Certified 12-ch Analog Input Module	12 (Differential)	V, mV, mA	12 sample/second (total)
	APAX-5013	8-ch RTD Module	8	RTD (2-wire or 3-wire)	10 (Total**)

Product Images	Model Name	Description	Channel	Output Type	Resolution	Datasheet
	APAX-5028	8-ch Analog Output Module	8	V, mA	14 bits

Product Images	Model Name	Description	Channel	Rated Voltage	Rated Current	Datasheet
	APAX-5046	24-ch Digital Output Module	24 x DO (Sink)	24 VDC	0.5 A
	APAX-5040PE	IEC 61850-3 Certified 24-ch Digital Input Module	24 x DI (Sink/Source)	24 VDC	3 mA
	APAX-5040	24-ch Digital Input Module	24 x DI (Sink/Source)	24 VDC	3 mA
	APAX-5045	24-ch Digital Input/Output Module	12 x DI (Sink/Source) 12 x DO (Sink)	24 VDC	DI: 3 mA DO: 0.5 A
	APAX-5060	12-ch Relay Output Module	12 x Relay (Form A, SPST)	250 VAC, 30 VDC	5 A
	APAX-5060PE	IEC 61850-3 Certified 12-ch Relay Output Module	12 x Relay (Form A, SPST)	250 VAC, 30 VDC	5 A

Product Images	Model Name	Description	Channels and Modes	Counter Frequency	Counting Range	Datasheet
	APAX-5080	4/8-ch High/Low Speed Counter Module	4	1 MHz (max.)	32-bit + 1-bit overflow/ underflow

Product Images	Model Name	Description	Protocol	Data transfer rate	Connected I/O Modules	Datasheet
	APAX-5070	Modbus/TCP Communication Coupler	Modbus/TCP	10/100 Mbps	32 (max.)*
	APAX-5072	EtherNet/IP Communication Coupler	Ethernet/IP	10/100 Mbps	32 (max.)*
	APAX-5071	PROFINET Communication Coupler	PROFINET RT, DCP, DHCP, TCP/UDP, DNS, SNTP, ICMP	100 Mbps	32 (max.)*
